The dimensions of the Haval Xiaolong are 4600×1877×1675 mm in length, width, and height, with a wheelbase of 2710 mm. The front and rear track widths are 1583 mm and 1587 mm respectively. The car can accommodate up to 5 people.
The Haval Xiaolong has a maximum power output of 116 PS, a maximum output power of 85 kW, and a peak torque of 140 N·m.
The Haval Xiaolong offers two types of batteries: lithium iron phosphate blade battery and ternary lithium battery. The highest battery energy capacity is 19.27 kWh. It provides a pure electric range of up to 96 km (WLTC cycle) and 110 km (NEDC cycle). It also supports fast charging with a power output of 33 kW.
Basic Information |
|||
| Top Speed(km/h) | 175 | WLTC Fuel Economy(L/100km) | 2.4/1.39 |
| Body | |||
| Length (mm) | 4600 | Width (mm) | 1877 |
| Height (mm) | 1675 | Wheelbase(mm) | 2710 |
| Front Track (mm) | 1583 | Rear Track (mm) | 1587 |
| Doors | 5 | Seats | 5 |
| Curb Weight (kg) | 1740/1810 |
Trunk Capacity (L)
|
420-1175
|
| Engine | |||
|
Displacement (mL)
|
1497 |
Displacement（L）
|
1.5 |
|
Intake System
|
Naturally Aspirated
|
Engine Layout
|
Transverse |
|
Cylinder Arrangement
|
L |
Number of Cylinders
|
4 |
|
Valves per Cylinder
|
4 |
Valve Train System
|
DOHC |
|
Maximum Power (kW)
|
74 |
Maximum Horsepower (PS)
|
100 |
|
RPM at Peak Power
|
6000
|
Maximum Torque (N·m)
|
132 |
|
RPM at Peak Torque
|
4400-5200
|
Fuel Tank Capacity (L)
|
- |
|
Fuel Grade
|
92 |
Emission Standard
|
China 6 |
|
Electric Motor
|
|||
|
Motor Brand
|
TZ220XS001
|
Number of electric motors
|
Single |
|
Motor Layout
|
Front |
Motor Type
|
PMSM |
|
Total Motor Power (kW)
|
115 | Number of Cylinders | - |
| Valves per Cylinder | - |
Total Motor Torque (N·m)
|
250 |
|
Front Motor Max Power (kW)
|
115 |
Front Motor Max Torque (N·m)
|
250 |
|
Battery/Charging (1.5L DHT)
|
|||
|
Battery Type
|
LFP battery/
Ternary lithium battery |
Cell Manufacturer
|
Svolt/
Gotion High-tech/Svolt
|
|
Battery Pack Capacity(kWh)
|
9.41/19.27
|
NEDC EV Range(km)
|
52/110 |
|
DC Fast Charging Time (min)
|
- |
DC Charging Capacity (%)
|
-
|
| Gearbox | |||
| Gears | 2 | Transmission |
DHT
|
| Chassis & Suspension | |||
| Drivetrain | FWD | Front Suspension | MacPherson Independent Suspension |
| Rear Suspension |
Multi-Link Independent Suspension
|
- | - |
| Tires & Brake | |||
| Front Brake | Ventilated Disc | Rear Brake | Solid Disc |
| Parking Brake | Electronic Parking Brake | Front Tire Specification |
225/60 R18
|
| Rear Tire Specification |
225/60 R18
|
||
| The specifications and configurations provided on this page are for reference only. Actual specifications are subject to the vehicle sold at the dealership. | |||
